The Airbus H145 D3 is a versatile twin-engine helicopter, widely used in emergency medical services (EMS), law enforcement, search and rescue, and utility operations. Below are the key specifications of the H145 D3
Chopper
Technical Specifications H145 D3
GENERAL SPECIFICATIONS
| Length | 13.00 meters (42 feet 8 inches) |
| Height | 4.06 meters (13 feet 4 inches) |
| Main Rotor Diameter | 11.00 meters (36 feet 1 inch) |
| Tail Rotor Diameter | 2.60 meters (8 feet 6 inches) |
| Maximum Takeoff Weight (MTOW) | 3,800 kg (8,378 lbs) |
| Maximum Speed | 248 km/h (154 mph or 134 knots) |
| Cruise Speed | 220 km/h (137 mph or 119 knots) |
| Range | 446 nautical miles |
| Service Ceiling | 20,000 feet (6,096 meters) |
| Endurance | Approximately 3 hours 15 minutes (depending on load and operating conditions) |
ENGINES
| Engines | 2 × Safran Arriel 2E turboshaft engines |
| Engine Power | 895 shaft horsepower (shp) each |
| Maximum Continuous Power | 1,013 shp each |
CABIN
| Seating Capacity | 1–2 pilots and up to 8 passengers (EMS or utility configurations may vary) |
| Cabin Dimensions | 2.16 meters (7 feet 1 inch) width, 1.40 meters (4 feet 7 inches) height, and 3.24 meters (10 feet 8 inches) length |
| Cargo Hook Capacity | 1,500 kg (3,307 lbs) |
AVIONICS & SYSTEMS
| Avionics Suite | Helionix digital avionics system (integrated flight deck with four-axis autopilot) |
| Display | 3 × 12-inch high-resolution multifunction displays (MFD) |
| Autopilot | 4-axis autopilot with automatic hover, approach, and go-around modes |
OTHER FEATURES
| Fenestron Tail Rotor | Provides quieter operation and enhanced safety. |
| Helicopter Performance | Advanced flight control system for easier handling and better operational efficiency. |
These specifications make the H145 D3 a high-performing, flexible aircraft for a variety of demanding missions.
